Hydroline TIFP – Tank Immersed Filter (Plastic Bowl)
The Hydroline TIFP combines an aluminium diecast body with a lightweight polyamide glass-filled plastic bowl, offering a cost-effective direct tank mounting option in five sizes to 175 LPM. Through-the-cover element replacement keeps service quick.
Key Specifications
- Construction: Aluminium diecast body; polyamide GF plastic bowl
- 5 models: TIFP-04, TIFP-06, TIFP-08, TIFP-06/08, TIFP-10
- Max flow: 175 LPM (TIFP-10)
- Working pressure: 10 bar (confirm — see flag below)
- Bypass valve: 1 bar standard
- Max temperature: 80°C
- Fluid: Mineral/petroleum based oils
- Port A (inlet): 1/2" (04) | 3/4" (06) | 1" (08) | 1-1/4" (10) BSPP
- Optional Port X (outlet): 3/4"–1-1/4" BSPP (selected models)
- Optional Port F (outlet): 3/4"–1-1/4" BSPP (selected models)
- Filtration grades: 10/25 µm nominal; 10/25 µm absolute
- Elements replaceable through cover
- Clog indicator: optional visual, ordered separately
- Weight: 0.9 kg (TIFP-04) to 4.0 kg (TIFP-10)
| Model | Port A Inlet (BSPP) | Optional Port X (BSPP) | Max Pressure (bar) | Bypass (bar) | Max Temp (°C) | Filtration Options (µm) | Weight (kg) |
| TIFP-04 | 1/2" | - | 10 | 1 | 80 | 10/25 nom; 10/25 abs | 0.9 |
| TIFP-06 | 3/4" | - | 10 | 1 | 80 | 10/25 nom; 10/25 abs | 1.5 |
| TIFP-08 | 1" | - | 10 | 1 | 80 | 10/25 nom; 10/25 abs | 1.7 |
| TIFP-06/08 | 1" | 3/4" | 10 | 1 | 80 | 10/25 nom; 10/25 abs | 1.8 |
| TIFP-10 | 1-1/4" | 1-1/4" | 10 | 1 | 80 | 10/25 nom; 10/25 abs | 4.0 |
