Sunfab SCPD Dual Flow Pump
The Sunfab SCPD 76/76 DIN is a compact dual flow gear pump delivering two equal, independent oil flows from a single unit. Built for direct mounting on gear boxes fitted with engageable power take-offs, it's a strong fit for applications needing high flow with a small installation footprint.
Key Specifications:
- Dual flow output: 127 + 127 L/min maximum (254 L/min combined)
- Displacement: 75 + 75 cm³/rev
- Maximum working pressure: 350 bar
- Maximum pump speed: 1500 rpm continuous, 1700 rpm limited
- Nominal torque at 350 bar: 418 + 418 Nm (836 Nm combined)
- Theoretical power at 350 bar / 1500 rpm: 65.6 + 65.6 kW (131.2 kW combined)
- Weight: 23.2 kg
- Available in left (L) or right (R) rotation
- O-rings on all contact surfaces and double shaft seals to prevent oil leakage
- DIN 4-h (ISO 7653-D) mounting flange, DIN 5462/ISO 14 splined shaft
